Description

Proxim SX3-1021A-QB-US QuickBridge™ 5 GHz Outdoor Wireless Bridge

Enterprise-Grade Point-to-Point & Backhaul Connectivity

The Proxim SX3-1021A-QB-US QuickBridge is a carrier-class 5 GHz outdoor wireless bridge engineered for organizations that require high throughput, RF stability, and long-term reliability. Built on the proven Proxim Stratum™ X3 platform, this solution delivers up to 1 Gbps throughput, advanced interference mitigation, and a rugged IP67 enclosure—ideal for enterprise backhaul, industrial networks, campuses, surveillance systems, and WISP infrastructure.

Unlike consumer or prosumer wireless bridges, the SX3-1021A-QB-US is purpose-built for mission-critical links where uptime matters and RF conditions are unpredictable.

---

Key Features & Benefits

High-Capacity 5 GHz Performance

• Operates in the 5.1–5.8 GHz band

• Up to 1 Gbps aggregate throughput

• 2×2 MIMO with adaptive modulation

• Supports 20 / 40 / 80 MHz channels

QuickBridge™ Deployment Advantage

• Optimized for fast point-to-point installation

• Ideal for building-to-building, site-to-site, and backbone links

• Reduces setup time without sacrificing enterprise performance

Integrated High-Gain Directional Antenna

• 22 dBi dual-polarized panel antenna

• Narrow beamwidth for improved noise rejection

• External antenna support available for custom RF designs

Rugged Outdoor Construction

• IP67-rated metal enclosure

• Designed for wind, rain, snow, heat, and industrial environments

• Built for permanent outdoor installations

Advanced RF & Traffic Optimization

• WORP® wireless protocol dynamically balances throughput and latency

• Excellent performance in congested RF environments

• Ideal for video, voice, and data backhaul

Enterprise-Grade Security

• AES-128 encryption standard

• Upgradeable to AES-256

• Secure management interfaces

Flexible Power & Networking

• Three Gigabit Ethernet ports

• PoE input and PoE output

• Power downstream devices such as cameras or remote access points

---

Technical Specifications

---

Why Buy the SX3-1021A-QB-US from GNS Wireless?

Anyone can sell hardware. GNS Wireless delivers solutions.

Premier Supplier of Outdoor & Industrial Wireless

GNS Wireless specializes exclusively in commercial-grade outdoor Wi-Fi and point-to-point wireless systems. We don’t push consumer gear—we design and support networks that are expected to work 24/7.

Real-World Design & Installation Expertise

• Free or assisted link planning and RF design

• Line-of-sight validation and antenna selection

• Mounting, grounding, and surge-protection guidance

• Optional turnkey installation services

Pre-Configured & Tested Equipment

We can ship your SX3-1021A-QB-US QuickBridge pre-configured, labeled, and tested—reducing deployment time and eliminating guesswork in the field.

U.S.-Based Technical Support

• Speak directly with experienced wireless engineers

• No call centers, no scripts

• Support before, during, and after installation

Built for Campgrounds, Marinas, Industrial Sites & Enterprises

From RV parks and marinas to utilities, farms, and industrial yards—GNS Wireless understands outdoor RF challenges and designs accordingly.

---

Frequently Asked Questions (FAQ)

Is this better than standard 5 GHz wireless bridges?

Yes. The SX3-1021A-QB-US is enterprise-class hardware designed for stability, interference mitigation, and sustained throughput—far beyond entry-level bridges.

Can GNS Wireless help design my link?

Absolutely. We regularly design point-to-point and backhaul links and can validate distance, antenna alignment, channel width, and expected throughput before you buy.

Is this suitable for video surveillance backhaul?

Yes. The high throughput, low latency, and PoE output make it an excellent solution for IP cameras and NVR backhaul.

Do you offer installation?

Yes. GNS Wireless offers professional installation services and remote deployment support depending on location and project scope.

---
