Radio Connector Guide

3Com®

Airconnect® Access Point 3CRWE747A   MMCX
3CRWE820096A, 3CRWE870075A, 3CRWE91096A, 3CRWE825075A, 3CRWE875075A, 3CRWE725075A   RP-SMA
ACKSYS®
WL-COMETH™, WL-ACCESS™, WL-DONGLE™, WL-LINK™, WL-ABOARD/S™, WL-ABOARD/N™, WL-IDA/S™, WL-IDA/N™   RP-SMA
Actiontec®
R3010WAP, GT701AP and AU802C Access Points   RP-SMA
GT704-WR, R3010SUW and R3010UW Wireless Routers   RP-SMA
AeroComm™
ConnexLink™ 2.4 GHz Model (CL5124-200-232)   RP-SMA
ConnexLink™ 900 MHz Model (CL4490-1000-232)   RP-SMA
Airespace®
Airespace® 1200 / 1200R Access Points   RP-TNC
AirMagnet®
AirMagnet® PC Cards   MMCX
Amtron
MW251   RP-SMA
Aperto Networks®
PW600S-25-01, PW600S-33-01, PW600S-35-01, PW600S-53-01, PW600S-58-01 PackWave® Wireless Bridge   N-Male
PWR2500, PWR3300, PWR3500, PWR5300, PWR5800 PackWave® Base Station Radio   N-Male
Aruba Networks™
AP 70   RP-SMA
Avaya®
Avaya®   MC Card
Apple®
G5 Mac   MCX-Plug (Male)
Apple PC Card (not AirPort® Extreme Base Station)   MC Card
Axxcelera Broadband Wireless
ExcelMAX™ Full Duplex FDD (FD-FDD) CPE   N-Male
ExcelMAX™ Half Duplex FDD (HD-FDD)/TDD CPE   N-Male
AB-Full Access II™ 50M/8TE, AB-Full Access II™ 100M/16TE   N-Male
AB-Full Access™ 50, AB-Full Access™ 100, AB-Full Access™ ET4, AB-Full Access™ ET8, AB-Full Access™ ET16   N-Male
Belkin®
F5D6001 / F5D7001 / F5D7000 PCI Card   RP-SMA
Blitzz®
BWA611 NetWave, BWA611B NetWave, BWA711 Super G, BWA721G, BWI605 NetWave, BWI715 Super G   RP-SMA
Bluesocket®
BlueSecure™ 1501 Access Point   RP-SMA
Breezecom® / Avarion®
AP/SA/WB-10D   RP-SMA
Buffalo™
Buffalo™ AirStation™ WHR-G54S, AirStation™ WHR-HP-G54S, AirStation™ WLI-TX4-G54HP, Wireless-G MIMO Performance Router & AP WHR-HP-G54   RP-SMA
WLI-CB-G54A AirStation™ PCMCIA Card, WLI-PCM-L11GP Airstation™ PCMCIA Card, WHR3-G54, WLA-G54, WLA-G54C, WBR2-B11, WLA-L11G, WLI-PCI-G54, WLI-TX1-G54, WRB-G54K, WLM2-G54   MC Card
Cisco Aironet®
Cisco® Aironet® Bridges 340/350/1200, PCI card, AIR-AP352E2R-x-K9, AIR-BR1310G-x-K9-R, AIR-PCI35x   RP-TNC
Cisco Aironet® 1230AG/1240AG Series 80211A/B/G Access Point   RP-TNC
Cisco Aironet® 1300 Series Outdoor Access Point / Bridge   RP-TNC
Cisco Aironet® 1400 Series Wireless Bridge   N-Male
Cisco Aironet® PC Card, AIR-LMC35x   MMCX
Clarion Wireless LAN
Clarion M10   SMA Male
CNet Technology
CWP-854 Wireless-G PCI Adapter   RP-SMA
Cognio®
Cognio® PC Cards   MMCX
Colubris Networks®
CN320, CN330, CN1250 , CN-3300
MAP-320, MAP-330
MSC-3200, MSC-3300, MGW-1250
MSC-3200R, MSC-3300R
MAP-320R
(Note: Older models used RP-N Plug connectors.)

MAP-330R
D-Link®
Air DWL-520, DWL-900AP, DI-713, DI-714, DI-614, PCI 520+
DI-524 AirPlus™ G, DI-514, DI-714P+, DI-824VUP, DWL-800AP+, DWL-810+, DWL-G700AP, DWL-G800AP
DI-624 (AirPlus Xtreme G™ 2.4GHz)
DGL-4300 (GamerLounge™ Wireless 108G Gaming Router)
DPG-2000W (AirPlus G™ 2.4GHz)
DWL-G810 (AirPlus Xtreme G™ High Speed 2.4GHz)
DWL-G510 (AirPlus G™ 2.4GHz)
DWL-G520 (AirPlus Xtreme G™ High Speed 2.4GHz)
DWL-1000AP+ (Air Premier™ 2.4GHz)
DWL-2000AP (AirPlus Xtreme G™ High Speed 2.4GHz)
DWL-2100AP (AirPlus Xtreme G™ High Speed 2.4GHz)
DWL-3200AP (Air Premier™ Managed AP)
DWL-8200AP (Air Premier™ Managed Dualband AP)

DI-514, DI-714P+, DI-824VUP, DWL-800AP+, DWL-810+, DWL-G700AP, DWL-G800AP
DIR-625 RangeBooster N™ Router – 802.11n
DIR-635 RangeBooster N™ 650 Router – 802.11n
DWA-542 RangeBooster N™ Desktop Adapter – 802.11n
DWA-547 RangeBooster N™ 650 Desktop Adapter – 802.11n

DWL-1750 (Air Premier™ Outdoor 2.4GHz 802.11b Wireless Bridge/Router)
DWL-1700AP (Air Premier™ Outdoor 2.4GHz 802.11b Wireless Access Point)
Dell®
Truemobile 1150 PC Card   MC Card
DrayTek®
Vigor2600VGi   RP-SMA
Vigor2600We   RP-SMA
Edimax
EW-7207APb, EW-7207APg, EW-7206APb Access Points   RP-SMA
BR-6104Wb, BR-6114Wg Routers   RP-SMA
EW-7126, EW-7128g PCI Cards   RP-SMA
Enterasys RoamAbout® / Cabletron
RoamAbout® AP4102, RoamAbout® AP1602 Access Points   RP-SMA
Enterasys® Legacy PC Card   MC Card
EnGenius®
NL-2511MP PLUS Mini-PCI Adapter
NL-3054CB PLUS Aries2 Mini-PCI Adapter
NL-3054MP PLUS High Speed Wireless Mini-PCI Adapter
NL-5354MP PLUS Aries2 Dual Band Wireless Mini-PCI Adapter
NL/SL-2511CD PLUS EXT2 PC Card
NL/SL-2511CD PLUS EXT2 Mercury PC Card
NL-5354MP
NL-5354MP PLUS Aries2
NL-2611CB3 PLUS Multi-Client Bridge / Client
NL-2611CB3 PLUS
NL-2511BG PLUS
SN-900, SN-920, EP-436, EP-490, DuraFon 1X and DuraFon 4X
EUB-362 EXT Wireless USB Adapter   RP-SMA
Foundry Networks®
IronPoint™ 200 Access Point   MC Card
Fortinet™
FortiWiFi-60 Access Point   RP-SMA
FreeWave®
FGR09TS, FGR09CS, FGR09CSU, FGR-5013008 and FGR09SE 900 MHz Spread Spectrum Radios
IM-510X008 and IM-500X008 2.4 GHz Ranger Series Radios
FGRM-501X005 and FGRM-511X005 900 MHz OEM Modules
FGR-115RC, FGR-115WC and FGR-115RE 900 MHz Wireless Radios
IM-800X009, IM-8001009 and IM-900X009 2.4 GHz Wireless Radios
IM-510X007 2.4 GHz Wireless Radio
Hawking®
HWR54G, HWBA54G, HWP54G   RP-SMA
Hewlett-Packard® / Compaq®
ProCurve® 420NA Access Point   RP-SMA
ProCurve® 420WL Access Point   RP-SMA
ProCurve® 420WW Access Point   RP-SMA
IBM®
IBM® Wireless PC Card, IBM Wireless AP500   MC Card
Intel®
Intel® PRO/Wireless AP WEAP2011BK   RP-BNC
Intel® PRO/Wireless AP WPCI5000   RP-SMA
Intellinet®
All wireless routers and access points with removable antennas   RP-SMA
Linksys®
Linksys® WAP11, WRT54G, WRT54GS, WAP54G, BEFW11S4, WSB24 Signal Booster   RP-TNC
Linksys® WET11, WET54G, WMP11 (PCI), WPS11   RP-SMA
Linksys® WMP54G, WMP54GS, WRT54GC   RP-SMA
Linksys® WAP54GPE
MaxStream®
24XTend™ 2.4 GHz OEM RF Module
24XTend™ 2.4 GHz OEM RF Module
9XStream™ 900 MHz OEM RF Module
9XStream™ 900 MHz OEM RF Module
9XTend™ 900 MHz OEM RF Module
9XTend™ 900 MHz OEM RF Module
XStream-PKG-R™, XStream-PKG-U™, XStream-PKG-E™ and XStream-PKG-T™ 900 MHz/2.4 GHz RF Modems
XPress™ 900 MHz Ethernet Bridge
9XTend-NEMA™ 900 MHz RF Modem
9XTend-PKG-R™, 9XTend-PKG-U™ and 9XTend-PKG-E™ 900 MHz RF Modems
9XCite™ 900 MHz OEM RF Modems
9XCite-PKG-R™ and 9XCite-PKG-U™ 900 MHz RF Modems
XBee™ and XBee-PRO™ 2.4 GHz OEM RF Modules
XBee-PRO PKG-R™ and XBee-PRO PKG-U™ 2.4 GHz RF Modems
Meru Networks®
Meru Networks® AP200   RP-SMA
Microwave Data Systems®
MDS iNET 900™   TNC-Male
Motorola®
Motorola® WR850G Wireless Router, WA840G, WPCI810G   RP-SMA
Motorola® / Nextel® iM1100 Wireless Modem   Straight MMCX
Motorola® MX360, STX, HT1000, MT2000 and Visar 2-Way Radios   SMA Female
Navini™
Ripwave® Modem   MCX-Plug (Male)
Netgear™
FM114P, FVM318, FWG114P, MA311, ME101, ME103, WG302   RP-SMA
WG311 / WG311T Wireless PCI Adapter   RP-SMA
Nextel®
Motorola® / Nextel® iM1100 Wireless Modem   Straight MMCX
Nokia®
Nokia® PC Card   SMA Right Angle
Nomadix®
AG-2000-w – Wireless Gateway™   RP-SMA
Nortel®
2230 Access Point   RP-TNC
2231 Access Point   RP-TNC
Nurit®
Nurit® 3010 Wireless Credit Card Terminal   TNC-Male
Proxim®
PC Card Gold (8470-FC/8470-WD/8420-WD), PC Card Silver (8471-WD)   MC Card
Proxim ORiNOCO® AP-600/AP-700*/AP-4000
*All models except Part #:8675-US2 which has no external connectors
  AP-600/700/4000 Compatible
Proxim ORiNOCO® 802.11a/b/g PCI Card #8482-WD   MCX-Plug (Male)
Proxim RL/2 Bridge   RP-SMA
Proxim RL/2 PC Card, Airconnect AP 3CRWE747A, Proxim Harmony 802.11 PC Card   MMCX
Proxim Harmony 802.11 PC Card   RP-MMCX
Proxim Harmony 802.11 AP, Stratum MP   RP-TNC
Proxim Mini-PCI Components   U.FL (Hirose™/iPax/Mini-PCI )
QPCOM®
QP-W102 (11b access point)   RP-SMA
QP-WR804B (11b wireless internet router)   RP-SMA
QP-WR914G (11g wireless internet router)   RP-SMA
QP-W2400GP (11g PCI adapter)   RP-SMA
QP-WP2000 ( 11b PCI adapter)   RP-SMA
QP-WA252G (54 Mbps Wireless AP)   RP-SMA
QP-WR254G (54 Mbps Wireless Router)   RP-SMA
QP-W2400GP+ (54 Mbps Wireless PCI adapter)   RP-SMA
Samsung MagicLAN®
Samsung MagicLAN® PC Card   MMCX
Senao®
NL-3054CB3 Plus Deluxe, NL-2611WD3 Plus, NL-2611CB3 Plus   RP-TNC
NL-2511AP Pro Plus   TNC-Male
NL-2511BG Plus, NL-2511HS Plus, NL-2511BG2 Plus   N-Male
NL-2511CD Plus, NL-2511CD Plus EXT2 Mecury   MMCX
WMP-3000, NL-3054MP PLus, NL-5354MP Plus, NL-5354MP Plus Aries2   U.FL (Hirose™/iPax/Mini-PCI )
NL-3054PCI Aries   SMA Male
Siemens®
SpeedStream® SS1024   RP-SMA
CONNECT2AIR™ AP-600RP-USB, CONNECT2AIR™ E-1100 PCI Card GRE: Gina 2015 AP/Bridge   RP-SMA
Sierra Wireless®
Sierra Wireless AirCard® 300   SMA-Nano/SSMB-Nano Plug
Sierra Wireless AirCard® 350   SMA-Nano/SSMB-Nano Plug
Sierra Wireless AirCard® 550   SMA-Nano/SSMB-Nano Plug
Sierra Wireless AirCard® 555   SMA-Nano/SSMB-Nano Plug
Sierra Wireless AirCard® 580   MC Card
Sierra Wireless AirCard® 750   SMA-Nano/SSMB-Nano Plug
Sierra Wireless AirCard® 860   SMA-Nano/SSMB-Nano Plug
Sierra Wireless AirCard® 875   SMA-Nano/SSMB-Nano Plug
smartBridges
airPoint™ XO   N-Male
airPoint™ XO2   N-Male
airPoint™ PRO   N-Male
airPoint™ PRO TOTAL   N-Male
airPoint™ Nexus SB3210   N-Male
airPoint™ Indoor   RP-SMA
airBridge™ Indoor   RP-SMA
airBridge™ Outdoor   N-Male
airBridge™ TOTAL   N-Male
airNIC®   RP-SMA
SMC®
SMC® AP/Bridge   RP-TNC
SMC® 2655W   MCX-Plug (Male)
SMC® 2665W   MCX-Plug (Male)
SMC2552W-G, SMC2582W-B, SMC2586W-G, SMC2602W, SMC2802W, BARRICADE SMC2804WBR, BARRICADE SMC2804WBRP-G   RP-SMA
SMC2555W-AG, SMC2532W-B, SMC25122-B   RP-MMCX
SonicWall®
TZ 170 SP Wireless, TZ 170, SonicPoint G   RP-TNC
Sony Ericsson® / Cingular Wireless®
Sony Ericsson® / Cingular Wireless® EDGE GC75, GC82, GC83, GC85 PC-Cards   S/E Type 237
Sony Ericsson® / Cingular Wireless® EDGE GC89 PC-Card   MMCX
Sputnik®
Sputnik AP 160™   RP-SMA
Sputnik AP 200™   N-Male
Symbol®
Symbol® AP300 Access Point (802.11a Radio)   RP-SMA
Symbol® AP300 Access Point (802.11b/g Radio)   RP-BNC
Symbol® AP-3020, AP-3021, AP-4131 Access Points   RP-BNC
Symbol® AP-5131 Access Point   RP-SMA
Symbol® LA-3021 Client Adapter PC Card   MMCX
Trango Broadband Wireless®
M2400S   RP-SMA
M900S   RP-SMA
TRENDnet®
TEW-203PI, TEW-228PI, TEW-403PI and TEW-423PI Wireless PCI Adapters   RP-SMA
TEW-223PI and TEW-303PI PCI Network Adapters   RP-SMA
TEW-231BRP and TEW-431BRP Wireless Routers   RP-SMA
TEW-2K1 Wireless Router / PC Card Kit   RP-SMA
TEW-435BRM Wireless Firewall Router   RP-SMA
Tranzeo®
XI-325, XI-325H, XI-325HP   MMCX
Trapeze Networks™
Mobility Point™ 352 (MP-352), Mobility Point™ 372 (MP-372)   SMA Male
Toshiba®
Toshiba® AP   MC Card
Ubiquiti Networks
Ubiquiti Cardbus 802.11a/b/g   MMCX
U.S.Robotics®
USR2450 Access Point Wi-LAN: AWE 45-24   RP-TNC
USR 8022, USR2216, USR5416, USR5430, USR5450, USR8054, USR9106   RP-SMA
WaveAccess
WaveAccess 132   RP-SMA
Vivato®
VA2200 AP/Bridge   RP-TNC
WaveRider®
WaveRider®   WaveRider
Westell®
VersaLink™   RP-SMA
Wi-LAN®
Wi-LAN® AWE22/45   RP-TNC
Wi-LAN® AWE120-24   TNC-Male
Wi-LAN® AWE120-58   N-Male
Zcomax® / Zcom
Zcomax® XI-300/325/325H/325HP/325HP2/1000   RP-MMCX
Zcomax® WL420/431/450, XG-1000, XI-626/1500/1500H/1500HP/3000, 1500HP2   RP-SMA
Zcomax® XG-900, XI-625   U.FL (Hirose™/iPax/Mini-PCI )
Zoomair®
Zoomair® PC Card 4105 / 4103   RP-SMA
ZyXEL®
ZyAIR® B-1000 Access Point   RP-SMA
ZyAIR® B-2000 Access Point   RP-SMA
ZyAIR® B-3000 Access Point   RP-SMA
ZyAIR® B-5000 Access Point (U.S. Models)   RP-N Plug
ZyAIR® B-5000 Access Point (EU Models)   N-Male
ZyAIR® G-2000 Access Point   RP-SMA
ZyAIR® B-101 PC Card   MMCX
Prestige 660HW ADSL Gateway   RP-SMA
