4×4 MIMO, 4.9 – 6.4 GHz Sector Antenna, 22 dBi Gain, 4x N-Female

$399.00

Part #: GNS-N545X4

4×4 MIMO, 4.9 – 6.4 GHz Sector Antenna, 22 dBi

Brand:
Availability: In Stock
Categories: , , , ,

Description

4×4 MIMO Antenna, 4.9 – 6.4 GHz Mimosa Sector Antenna, 22 dBi Gain, 4x N-Female

22 dBi Gain, 4×4 MIMO Sectorized Panel Antenna for 802.11AX, and 4×4 MIMO Access Points and Radio modules. This Mimosa sector antenna will support third party access points. It uses 4x N-Female connectors.  Contact GNS Wireless for coaxial cable assemblies.

Frequency Support:  4.9 to 6.4 GHz

Connectors:  4x N-Female

Gain:  22 dBi

Beamwidth:  45 Degrees

Front to Back Ratio:  43 dB



Applications:

  • High Speed Internet WISP
  • Public Safety Networks
  • 802.11AX Access Points
  • Fixed 5G Wireless Deployments
  • UHD Security Cameras
  • High Gain



Overcoming noise at tower sites is key to scaling capacity. The N5-45×4 delivers industry-leading side lobe rejection and an unprecedented 43 dB front-toback (FTB) performance — the highest FTB ratio of any sector or horn antenna in the industry. When used in combination with the Mimosa A5c access point, there’s no higher performance tower solution to deliver full 2x spectrum reuse.

Supporting 4.9 GHz public safety applications and multipoint licensed operation up to 6.4 GHz (where regulations allow), the N5-45×4 802.11AX antenna provides an additional 800 MHz of spectrum beyond the crowded 5.15–5.85 GHz unlicensed channels.

Additional information

Weight 25.0000 lbs
Availability

In Stock

Downloads

N5-45_Datasheet Size: (1.12 MB)
