EG6000 Edge Gateway Bundle
The EG 6000 is the latest and most advanced bandwidth management gateway in the Nomadix lineup. This new gateway is designed to be at the network edge for Multi-Dwelling Units (MDUs) including apartment buildings, condominiums, student housing and assisted living facilities.
The Nomadix EG 6000 is a high-performance Internet access gateway designed for use in hotels, resorts, airports, convention centers, and other public venues that require a robust, scalable, and reliable Wi-Fi solution. Here are the specifications for the Nomadix EG6000:
- Network Interfaces: 6x Gigabit Ethernet ports
- WAN Connectivity: 2x 10/100/1000Mbps Ethernet ports for redundant connectivity or load balancing
- Authentication: Supports a variety of authentication methods including PMS/HSIA integration, RADIUS, LDAP, and local user database
- Bandwidth Management: Provides bandwidth control by user, group, and application with Quality of Service (QoS) settings
- Security: Offers various security features such as firewall, VPN pass-through, and intrusion prevention system (IPS)
- User Access: Supports up to 8,000 simultaneous users with the ability to scale up to 20,000 users with additional licenses
- Content Filtering: Offers URL filtering and content filtering with the ability to block or allow specific sites or categories
- Management: Provides web-based management interface and remote management options including SNMP, SSH, Telnet, and serial console
- Power Supply: AC input voltage of 100-240V and DC output voltage of 12V
- Dimensions: 1.72″ x 17.24″ x 11.53″ (44 x 438 x 293mm)
- Weight: 8.6 lbs (3.9 kg)
In conclusion, the Nomadix EG6000 is a high-performance Internet access gateway that offers a range of features including authentication, bandwidth management, security, user access, and content filtering. It is designed for use in public venues and can support up to 8,000 simultaneous users with the ability to scale up to 20,000 users. Its web-based management interface and remote management options make it easy to configure and manage. With six Gigabit Ethernet ports, the EG6000 can handle large volumes of traffic and is suitable for high-density environments.
