ValuePoint 1000mW Outdoor Access Point with Multi-SSID Support- 2.4GHz


Contact Us

Part #: GNS-AP770G

2.4GHz 1000mW Outdoor Access Point with Multi-SSID Support

Availability: Out of Stock
MFG Part #: AP770G


Outdoor, Weatherproof Access Point with 1000mW transmit power. N-Female connector for external antenna, 2.4GHz 802.11b/g, POE Support. Mulit-SSID Support, VLAN Support.

Repeater functionality
The outdoor access point is able to operate as a repeater in addition to an access point, allowing it to communicate with other compatible AP/routers to form a Wireless Distribution System. This greatly extends the reach of the your wireless network. Using omni antennas and the unit’s powerful 1000 mW radio, an extended range is possible.  This becomes useful when trees, or other obstructions prevent you from covering your specified area with a single access point.  Multiple access points can be used to create a large Wi-Fi network, making it easier and more efficient for your guests to get online.  Up to six WDS links can be established from a single unit


Technical Specifications


1 Watt transmit power adjustable radio
Data Rates: OFDM @ 54Mbps, CCK @ 11/5.5 Mbps
QPSK @ 2 Mbps and DBSK @ 1Mbps
AP Range 3000m line of sight (client dependant)
WDS Range 20,000m line of sight (antenna dependant)
-102 dBm – -92 dbm receive sensitivity b mode
-96 dBm – -80 dBm receive sensitivity g mode
1 10/100 ethernet LAN port
802.3af 48v Power over Ethernet
NEMA-style enclosure with moisture proof seals
10.8 x 8.3 x 4 in. / 3.6 lbs


31 SSIDs
DHCP client and server

Security and Management Features

40(64) or 128 bit WEP
traffic and event logging, syslog
snmp v 1, II, 802.11
wpa2 aes
web based management
remote firmware upgrade
QOS 802.1p Priority Tagging

Certification and Approval

CE Mark
FCC part 15 class B
VCCI Class B


Additional information

Weight 10.0000 lbs
