Description
20 x 16 x 11 Weatherproof Enclosure with 120 VAC Power & Cooling Fans
A professional outdoor enclosure designed to protect wireless, networking and electronic equipment in demanding installations. This 20 x 16 x 11 inch Gen 2 enclosure combines rugged fiberglass construction, an integrated 120 VAC powered mounting plate and automatic thermostat-controlled cooling fans in one clean, ready-to-install package.
More Room for Outdoor Network Equipment
Outdoor electronics need protection from weather, dust, corrosion and excessive temperatures. They also need enough internal space for proper equipment mounting, cabling and airflow.
This 20 x 16 x 11 inch powered enclosure provides substantially more usable depth than smaller outdoor cabinets, making it an excellent choice for installations containing multiple network components or larger equipment.
The enclosure combines a rugged fiberglass cabinet with an internal 120 VAC powered mounting plate and automatic fan cooling. It is ideal for housing wireless radios, PoE injectors, Ethernet switches, routers, power supplies, cellular equipment, surveillance electronics and industrial controls.
Ideal Applications
Rugged Fiberglass Construction
The enclosure is manufactured from molded UV-stable Fiberglass Reinforced Polyester (FRP), making it well suited for outdoor, high-temperature and corrosive environments. Unlike conventional steel cabinets, fiberglass will not rust, making it an excellent choice for outdoor wireless and network installations.
A fully gasketed raised lid helps protect equipment from the elements. Stainless steel quick-release latches provide convenient access, while integrated padlock hasps allow the enclosure to be secured when installed in publicly accessible or remote locations.
- 20 x 16 x 11 inch enclosure
- Molded UV-stable fiberglass reinforced polyester (FRP)
- Tool Gray – RAL 7035 finish
- Fully gasketed raised lid
- Stainless steel hardware
- Quick-release latches with padlock hasps
- Integral mounting flange
- Mast mounting option available
Integrated 120 VAC Powered Mounting Plate
The Gen 2 powered mounting plate provides a clean, organized platform for installing and powering networking and electronic equipment inside the enclosure.
Duplex 120 VAC outlets provide convenient power for devices such as PoE injectors, switches, routers and power supplies. A DIN-rail-mounted terminal block simplifies connection of incoming power, while the integrated grounding lug provides a dedicated grounding point.
The universal slotted mounting design provides flexibility when positioning equipment and accessories, allowing installers to create a clean layout without being restricted to a fixed mounting pattern.
Power Distribution: Duplex AC outlets
Incoming Power: DIN-rail-mounted terminal block
Grounding: Integrated grounding lug
Equipment Mounting: Universal slotted mounting design
Automatic Thermostat-Controlled Cooling
Equipment installed inside an outdoor enclosure can generate considerable heat, especially during the summer months. Excessive internal temperatures can reduce equipment life, cause unexpected shutdowns and affect network reliability.
The integrated high-airflow, low-noise fan system automatically activates as the internal temperature rises, moving air through the enclosure to help maintain a better operating environment for installed electronics.
Fan system power: 12 watts.
Why Choose the 20 x 16 x 11 Size?
The additional 11-inch enclosure depth provides valuable room for installations using larger power supplies, multiple PoE injectors, Ethernet switches and other network components. The extra space also makes cable management easier and provides more room around equipment for airflow and servicing.
Enclosure, Power & Cooling — All in One
Instead of assembling a separate outdoor cabinet, mounting plate, AC power system and cooling components, this enclosure provides an integrated solution designed for professional installations. Simply install your equipment, connect power and complete your field wiring.
Technical Specifications
Need Help Selecting an Outdoor Enclosure?
Not sure which enclosure size or environmental-control option is best for your equipment? GNS Wireless can help match the enclosure to your equipment and installation environment. Contact us before ordering and we’ll help you select the right configuration.
